LED Screen Specifications

Screens for Rent - LED Display Screen Specifications
Model SM16
  Pixel Pitch
8mm

Panel Depth
150mm
  Vertical Viewing Angle
±35˚

Panel Weight
70kg
  Horizontal Viewing Angle
±55˚

Panel Area
0.79 m²
  Processing
14 bit

Panel Material
Steel
  Lifetime
10000 hours

Aspect Ratio - Wide Screen
16:9
  Brightness
6500 nits

LED per m²
15624
  Pixel & Configuration Type
2R, 1G, 1B

Minimum Viewing Distance
15 m or beyond
  Panel Width
1024mm

Operating Temperature
-20˚C  +60˚C
  Panel Height
768mm

Operating Humidity
25% 95% RH
  Protection Rating
IP 65/54

Refresh Rate
600 Hz
  Brightness Control
255
   Grey Scale
16K
  Interface
DVI
   Voltage
3 phase 208/220
  Power Frequency
50/60 Hz
   Power Consumption
Max 1200w / Average 500w



Screens for Sale -LED Display Screen Specifications
Model
SM10
SM12
SM16
SM20
SM20B
Pixel Pitch
10mm
12mm
16mm
20mm
20mm
Virtual Resolution
-
6mm
8mm
10mm
10mm
Vertical Viewing Angle
±35˚
±35˚
±35˚
±35˚
±35˚
Horizontal Viewing Angle
±55˚
±55˚
±55˚
±55˚
±55˚
Processing
16 bit
14 bit
14 bit
14 bit
16 bit
Lifetime
10000 hours
10000 hours
10000 hours
10000 hours
10000 hours
Brightness
9000cd\m²
7500cd\m²
7000cd\m²
5200cd\m²
5000cd\m²
Pixel & Configuration Type
1R, 1G, 1B
2R, 1G, 1B
2R, 1G, 1B
2R, 1G, 1B
2R, 1G, 1B
Panel Width
800mm
960mm
1024mm
1280mm
1280mm
Panel Height
640mm
768mm
768mm
960mm
960mm
Panel Depth
150mm
150mm
150mm
150mm
150mm
Panel Weight
55kg
60kg
70kg
75kg
75kg
Panel Area
0.52 m²
0.74 m²
0.79 m²
1.23 m²
1.23 m²
Panel Material
Steel
Steel
Steel
Steel
Steel
LED per m²
27776
27776
15624
10000
10000
Minimum Viewing Distance
15 m or beyond
15 m or beyond
15 m or beyond
30 m or beyond
30 m or beyond
Operating Temperature
-20˚C  +60˚C
-20˚C  +60˚C
-20˚C  +60˚C
-20˚C  +60˚C
-20˚C  +60˚C
Operating Humidity
25% 95% RH
25% 95% RH
25% 95% RH
25% 95% RH
25% 95% RH
